SKU:MFP63
Mason-Lite 63" Pre-Cast Masonry Firebox Kit
Mason-Lite 63" Pre-Cast Masonry Firebox Kit
Gas Log and Burner
-- Please Select --
48 in. Natural Gas Jumbo Virginiana Decorative Gas Logs and Burner for use with MFP63
48 in. Liquid Propane Jumbo Virginiana Decorative Gas Logs and Burner for use with MFP63
No, Thank You
Brick Panels
Metal Base
-- Please Select --
8 in. Structural Metal Base for 63 in. Firebox
No, Thank You
Air Kit
-- Please Select --
4 in. Combustion Air Kit -3' Flexible Vent and Plastic Hood
No, Thank You
Height Kit
-- Please Select --
Height Kit Includes (1) MFP63-2 (1) MFP63-2A & (2) MFP63-3
No, Thank You
Damper
-- Please Select --
54 in. Cast Damper - for MFP63 (DAMPER BLOCK - MFP63 Included)
Damper Block for MFP63
No, Thank You
Burner Set
-- Please Select --
Natural Gas Pureburn Grate/Burner Set for MFP63
Propane Pureburn Grate/Burner Set for MFP63
No, Thank You
Ignition
-- Please Select --
No, Thank You
Chimney Shrouds
-- Please Select --
32 in. Natural Copper Arlington Chimney Shrouds
32 in. Matte Black Arlington Chimney Shrouds
32 in. Dark Bronze Arlington Chimney Shrouds
32 in. Storm Gray Arlington Chimney Shrouds
36 in. Natural Copper Dover Chimney Shrouds
36 in. Matte Black Dover Chimney Shrouds
36 in. Dark Bronze Dover Chimney Shrouds
36 in. Storm Gray Dover Chimney Shrouds
40 in. Natural Copper Sussex Chimney Shrouds
40 in. Matte Black Sussex Chimney Shrouds
40 in. Dark Bronze Sussex Chimney Shrouds
40 in. Storm Gray Sussex Chimney Shrouds
40 in. Natural Copper Charleston Chimney Shrouds
40 in. Matte Black Charleston Chimney Shrouds
40 in. Dark Bronze Charleston Chimney Shrouds
40 in. Storm Gray Charleston Chimney Shrouds
No, Thank You
- Free Shipping on Orders Over $300
- Same-Day Order Processing
Overview
Have you ever dreamed of the radiant warmth of a masonry fireplace in your bedroom? Or, do you dream of an outdoor fireplace where you can gather together with friends and loved ones? Dreams can come true with Mason-Lite masonry fireplaces. Our factory-built masonry fireboxes are affordable, easy to handle, and consistent in quality. A masonry fireplace adds luxury and increases the value of your home.
Recreating the tradition of the hearth and the elegance & romance of the flame, Mason-Lite captures the essence of the fireplaces masonry artists have been crafting for centuries. And, with a proven history of superior quality, lightweight fireplaces for indoor and outdoor projects, it’s no wonder Mason-Lite is one of the industry leaders of modular concrete fireplaces.
At Mason-Lite, we use the finest aggregate materials available to build our lightweight modular concrete fireplaces. One of the main ingredients is pumice, a naturally fired volcanic rock with tremendous strength.
Its lightweight attributes are second to none, and because of its pre-fired beginnings, pumice retains heat better than any natural aggregate available. The best sources for USA pumice are in the western states, convenient to Mason-Lite’s California-based production facilities. Pumice is formed when gas-rich, frothy magma rapidly cools, creating air pockets that contribute to its remarkable lightweight properties.
Because it is only half the weight and half the cost of traditional masonry fireplaces, Mason-Lite Lightweight Masonry Fireplace Systems help you realize your dream of having a fireplace in your master bedroom, upstairs retreat, or even your outdoor patio, without major building infrastructure reinforcement. The restful flicker and comfortable glow of the fire will provide you with years of treasured memories.
With the help of ICC-ES, Mason-Lite developed the structural testing and performance criteria (AC375) that would comply with the International Building Code (IBC), the International Residential Code (IRC), and the International Fuel Gas Code (IFGC). This allows building officials throughout the US to confirm that Mason-Lite fireplaces meet these stringent codes.
Why Choose Mason-Lite:
The Perfect Fireplace for Indoor or Outdoor Projects:
The MFP63 has a finished opening of 60” W x 30.5” H and is a standalone unit that can be built indoors or outdoors to burn wood or gas. Made from the same lightweight material as the other Mason-Lite fireplaces allow this unit to be installed on decks and other wood framings. Available accessories include full running bond and split herringbone brick liners in standard sizes.
Features
- Available in 33", 33-P, 39", 44", 49", and 43" See-Thru models
- Lightweight construction with multiple firebox sizes available
- Best fit and finish in the industry
- Available for Indoor/outdoor, wood-burning, natural, and propane gas systems
- Allowed for multi-story combustible floor installations
- Superior thermal efficiencies with the highest resistance strength at 28 days
- Complies and tested with UL 127 & UL 103 chimney component standards
- Optional herringbone or running bond firebrick panels for easy installation
- Heat resistant fire tested up to 1700 Degrees Fahrenheit
- Less expensive shipping and handling costs
- 50% cheaper than a traditional hand-built masonry fireplace
- All kits come complete with Refractory Mortar. Rebar. and T-bar
- Limited Lifetime warranty
- Made in the U.S.A.
Specifications
Model | MFP63 |
Finished Opening Dimensions | 60" (W) x 21.5" (D) x 30.5" (H) |
Total Unit Height | 70.25" |
Footprint | 67" x 28" |
Flue Diameter - Class A | 16" ID |
Clearance to Combustibles* (Sides and Back) | 2" |
Framing Dimensions | 71" (W) x 30" (D) x 72.25" (H) |
Floor Area(67x28) | 13.03 sq. ft. |
Fireplace Weight | 2,558 lbs. |
Mortar and Rebar | 130 lbs. |
Ready Mix | 250 lbs. |
Masonry Chimney weight per foot | N/A |
Metal Chimney weight per foot | 12 lbs. |
Installation Type | Flush Installation / Corner / Internal Wall / Full Projection |
Warranty | Limited lifetime warranty |
Product Inclusions
Click to see details
Refractory Mortar |
Rebar and T-Bar |
Optional Accessories
Click to see details
MFP63SHBL Split Herringbone Brick liner Mason-Lite offers true firebrick panels for quick and easy installation. Two color options: Standard Buff and Red |
|
MFP63FRBL Full Running Bond Brick liner Mason-Lite offers true firebrick panels for quick and easy installation. Two color options: Standard Buff and Red |
|
MFP63SRBL Split Running Bond Brick liner Mason-Lite offers true firebrick panels for quick and easy installation. Two color options: Standard Buff and Red |
|
MFPB63 8" Structural Metal BaseOur 6” and 8” bases are used for installations on combustible floors or second-story applications. |
|
MFP4-AK Combustion Air Kit Because homes are being built so tight, many jurisdictions are requiring additional outside air to make up for negative air pressure. For convenience, the kit comes pre-drilled for this application. |
|
MFP-Arc63 Masonry Arch The masonry arch kit consists of 2 pieces that can easily be mortared in to give a custom look. |
|
MFP63-HK Height Kit This Height Kit consists of a rear wall and two side walls that will increase the height opening by 8" from the standard opening (giving a Rumford look). With the new size opening be sure to check the Chimney Size Chart to ensure proper flu size. |
|
16ATGAPD Anchor/ Damper Plate Dampers are required for indoor applications. Mason-Lite offers several damper options: metal anchor plate/damper for masonry chimney; cast-iron damper (damper blocks included); anchor plate/damper for metal chimney |
|
Premium Chimney Shrouds Mason Lite’s Decorative steel and copper chimney pots offer an alternative to unsightly factory flue caps and terminations, improving the aesthetics of chimney tops |
Masonry Chimney Systems
The MFPST43, MFP63, or and MFP75 would need to be ordered specially to use dual 14" Masonry Chimney and would have a maximum system height of 20'.
Click Here for more details
Class A Air-Cooled Metal Chimney System
DuraChimney® II is an exceptional factory-built alternative to pre-fabricated masonry chimneys.DuraChimney® II is a unitized, lightweight design that eliminates the need for field assembly of pipe sections, allowing for faster installation.
Click Here for more details
Click Here to Shop for Class A UL103 Chimney Systems
Downloads
Attention: You may need a residential building permit to install a Mason-Lite Fireplace. Consult local jurisdictions before you get started!
